D-C8
Serial NO.:Thermographic Telescope
Specification
Product Description
Thermographic Telescope
Detector type: uncooled focal plane
Infrared resolution: 384x288
LCD resolution: 1024*768
Focal length: 25mm, 35mm,
Eyepiece: Monocular display (adjustable for curved light correction)
"Field of view:
14.9°x11.2°, 10.7°x8.0°;
6.9°x5.2°, 5.0°x3.7°;"
Digital zoom: 2x; 4x
Wavelength range: 8~14μm
Thermal image frame rate: 50Hz
Palette: Rainbow, Hot Metal, White Hot, Black Hot
Focal length: adjustable
Battery: Built-in rechargeable 3.7V (2100MAH) battery
Image type: BMP
Storage space: 8G
USB: Type-C
Working time: 6 hours
Working temperature: 0℃ to 45℃
Storage temperature: -20℃ to 60℃
